Mini Power Relay is an electromagnetic or solid-state switching device with a small size and compact structure. Its core function is to use small current (coil side) to control the on/off of large current/high voltage (contact side) to achieve electrical isolation, signal amplification and logic control of the circuit. It is a basic control component in industrial automation, consumer electronics, automotive electronics and other fields.

1. Coil Electrical Parameters

• Rated Coil Voltage

  DC: 5V, 12V, 24V, 48V

  AC: 6V, 12V, 24V, 110V, 220V

• Coil Power Consumption: 0.2–1W (＜0.5W for low-power types)
• Coil Resistance: Dozens to thousands of ohms
• Pick-up Voltage: ≥75% of rated voltage
• Drop-out Voltage: ≤10% of rated voltage
• Max. Continuous Applied Voltage: ≤110% of rated voltage

2. Contact Electrical Parameters

• Contact Configuration

  NO (Normally Open), NC (Normally Closed), Changeover (1NO+1NC)

  1P/2P/4P changeover available

• Rated Contact Load (Resistive)

  General-purpose: 5A 250VAC / 5A 30VDC

  Low-power: 1A 30VDC / 3A 250VAC

  High-current compact type: 10A 250VAC / 10A 30VDC

• Contact Material: AgNi, AgCdO, AgSnO
• Dielectric Strength

  Coil to contact: ≥5kV AC

  Between contacts: ≥1kV AC

• Contact Resistance: ≤100mΩ (initial value)

3. Mechanical & Operating Parameters

• Operate Time: ≤10ms
• Release Time: ≤5ms
• Mechanical Life: ≥10,000,000 operations
• Electrical Life: ≥100,000 operations (rated resistive load)

4. Environmental Parameters

• Operating Temperature: -40℃ to +85℃
• Storage Temperature: -55℃ to +125℃
• Operating Humidity: 5%–85%RH (non-condensing)
• Vibration / Shock: Compliant with general industrial requirements

5. Physical & Mounting Parameters

• Typical Dimensions: 19.0×10.0×15.5mm
• Mounting Style: Through-hole (DIP), SMD, socket type
• Pin Count: 5 pins (1P changeover), 8 pins (2P changeover), 14 pins (4P changeover)
• Weight: approx. 5–15g
